Description
HOUSING AND FINISH
- Housing: Aluminum Alloy & Tempered Glass
- Housing finish: Powder coated
- Optic: Polycarbonate Lens
- IP Rating: IP66
- IK Rating: IK08
- Category of corrosion: C3
LIGHT SOURCE
- Lamp Type: LED SMD3030
- System wattage (W): 20W
- Colour temperature (K): 3 CCT (2700K, 3000K, 4000K)
- Nominal flux (lm): 2200Lm
- Efficacy: 110Lm/W
- Beam angle: 30°
- Lifetime of LEDs: L90-110000 ; L80-250000 ; L70-420000
ELECTRICAL INFORMATION
- Electrical class: I
- Input voltage: AC220-240V ~ 50/60Hz
- Power factor: >0.9
- Down Light Power: 10W
- Up Light Power: 10W
- Surge protection: 1.5kV line-line, 2kV line-earthDriver type: Constant Current (CC)
- Control options: Power adjustable, 2W3H Emergency backup
- Colour rendering index (CRI): Ra80
- Operating temperature range (Ta): 0 to + 40°C
APPLICATION AREAS
- Building exteriors
- Hotel lobbies
- Corridor and auditoriums to entryways
DIMENSIONS AND MOUNTING
- Length x Width x Height: 150 x 120 x 215mm
- Mounting: Wall mounting
- Weight: 2.74kg
WARRANTY
- Product: 5 Years
COLOUR
- Black
- White
- Grey
