Description
HOUSING AND FINISH
- Housing: Aluminium Alloy
- Housing finish: Powder coated
- Optic: Polycarbonate Optical Lens
- IP Rating: IP65
- IK Rating: IK08
LIGHT SOURCE
- Lamp Type: LED SMD2835
- System wattage (W): 200W
- Colour temperature (K): 3000K/4000K/5000K Selectable
- Nominal flux (lm): 36000Lm
- Efficacy: 180lm/W
- Beam angle: 90°
- Lifetime of LEDs: L90-50000 ; L80-100000 ; L70-160000
- Colour rendering index (CRI): Ra80
- UGR level: <28
ELECTRICAL INFORMATION
- Insulation Class: I
- Input voltage: AC120-240V ~ 50/60Hz
- Power factor: >0.95
- Power Consumption: 200W/160W/120W Selectable
- Surge protection: 6kV line-earth,6kV line-line
- Control: 1-10V DALI Dimmable, Microwave motion sensor, PIR sensor, Casambi
- Operating temperature range (Ta): -30°C to +50°C
APPLICATION AREAS
- Warehouse
- Food processing plant
- Exhibition center
- Shopping mall
- Gymnasium
- Airport
- Library
DIMENSIONS AND MOUNTING
- Length x Width x Height: Φ325 x 140mm
- Mounting: Loop hanging / Ceiling mounting
- Weight: 2.5kg
WARRANTY
- Product: 5 Year Warranty
COLOUR
- Black
